Specs
Engine Model
5901755
US MSRP ^
$14,049.00
CAN MSRP ^
$18,249.00
Fuel Capacity - gal (L)
2.5 (9.5)
Fuel Type
Regular unleaded gasoline, 87 octane or higher
Top Ground Speed (mph)
8
Front Tires
13" x 6.5 - 6
Rear Tires
20" x 10 - 12
Spreader Model
Spyker 220 Series
Spreader Hopper Capacity (lbs.)
200
Electric Spreader Motor
Standard
Variable Spread Width
3' to 25'
Spray Pump
4.0 gpm electric diaphragm pump
Sprayer Tank Capacity - gal (L)
24.0 (90.8)
Nozzles
4 - TT11003-VP
Spray Rate
1/4 gallon per 1,000 ft² at 20 psi
Productivity (sq. ft. per fill)
96,000 (1/4 gallon per 1,000 ft² at 20 psi at 5 mph)
Overall Length - in. (cm)
65 (165)
Overall Width - in. (cm)
39 (99.1)
Overall Height - in. (cm)
48 (121.9)
Dry Weight - lbs (kg)
627 (284.4)
Full Weight - lbs (kg)
939 (425.9)
Accessories Warranty
Standard: 1 year Rental: 90 days
Belts, Tires, Brake Pads, Hoses, Battery Warranty
Standard: 90 days Rental: 90 days
Engine Brand
Vanguard® V-Twin
Legacy Material Number
5901755
Operator's Manuals
Operator's Manual - English
Illustrated Parts List - English
Wiring Diagram Schematic - English
Illustrated Parts List - English
Wiring Diagram Schematic - English
* All power levels are stated gross horsepower at 3600 rpm per SAE J1940 as rated by Briggs & Stratton.
^ Suggested prices will vary by market. Price shown in US dollars. Set-up, delivery, documentation and destination fees not included. See dealer for details. Features vary by model. We reserve the right to change specifications, features and pricing without notice.
