Specs
Engine Model
5902195
US MSRP ^
$18,149.00
CAN MSRP ^
$24,501.00
Fuel Capacity - gal (L)
5
Fuel Type
Regular unleaded gasoline, 87 octane or higher
Top Ground Speed (mph)
8
Spreader Model
Spyker 220 Series
Spreader Hopper Capacity (lbs.)
200
Spray Pump
Quick Pin TeeJet 530 Manifold with Push-to-Connect (PTC) hose system
Sprayer Tank Capacity - gal (L)
24.0 (90.8)
Nozzles
4 - AIXR110025
Spray Rate
1/4 gallon per 1,000 ft²
Productivity (sq. ft. per fill)
72,000 (1/4 gallon per 1,000 ft² at 20 psi at 5 mph)
Overall Length - in. (cm)
65 (165.1 cm)
Overall Height - in. (cm)
48 (121.9 cm)
Dry Weight - lbs (kg)
39 (99.1 cm)
Full Weight - lbs (kg)
Dry: 627 lbs. (284.4 kg); Full: 939 lbs. (425.9 kg)
Accessories Warranty
Standard: 1 year Rental: 90 days
Belts, Tires, Brake Pads, Hoses, Battery Warranty
Standard: 90 days Rental: 90 days
GPM
5
Engine Brand
Vanguard® V-Twin
Operator's Manuals
* All power levels are stated gross horsepower at 3600 rpm per SAE J1940 as rated by Briggs & Stratton.
^ Suggested prices will vary by market. Price shown in US dollars. Set-up, delivery, documentation and destination fees not included. See dealer for details. Features vary by model. We reserve the right to change specifications, features and pricing without notice.
