Specs
Engine Model
5901753
US MSRP ^
$11,049.00
CAN MSRP ^
$14,349.00
RPM
Full Speed: 3750 RPM (No Load) Idle: 1400 RPM
Fuel Capacity - gal (L)
2.5 gal (9.5 L)
Fuel Type
Regular unleaded gasoline, 87 octane or higher
Fuel Shut-Off Valve
Located on engine and below tank
Transmission Model
Peerless 855 Series, coated for corrosion
Speed (mph)
Low Gear: 3.5 mph (5.6 km/hr) High Gear: 5.0 mph (8.0 km/hr)
Front Tires
18 x 9.5 - 8, RB antifreeze added for ballast and traction
Rear Tires
13 x 6.50 - 6
Spreader Model
Spyker 220 Series
Spreader Hopper Capacity (lbs.)
200
Spray Pump
2.0 gpm mechanically driven diaphragm pump
Sprayer Tank Capacity - gal (L)
16.0 (60.6)
Nozzles
Broadcast: Turbo FloodJet TF-VS5 Trim: TurboTeeJet TT11004VP
Spray Rate
1/4 gallon per 1,000 ft² at 20 psi
Productivity (sq. ft. per fill)
64,000 (1/4 gallon per 1,000 ft² at 25 psi at 5 mph)
Overall Length - in. (cm)
58.0 (147)
Overall Width - in. (cm)
35.5 (90)
Overall Height - in. (cm)
49.0 (124)
Dry Weight - lbs (kg)
450 (204)
Full Weight - lbs (kg)
670 (304)
Safety Interlock
This machine is equipped with a neutral safety start module. To start the engine, the transmission must be in the neutral (N) position.
Accessories Warranty
Standard: 1 year Rental: 90 days
Belts, Tires, Brake Pads, Hoses, Battery Warranty
Standard: 90 days Rental: 90 days
Engine Brand
Honda® GX200-URH2
Legacy Material Number
5901753
Operator's Manuals
Operator's Manual - English
Illustrated Parts List - English
Wiring Diagram Schematic - English
Illustrated Parts List - English
Wiring Diagram Schematic - English
^ Suggested prices will vary by market. Price shown in US dollars. Set-up, delivery, documentation and destination fees not included. See dealer for details. Features vary by model. We reserve the right to change specifications, features and pricing without notice.
