Specs
US MSRP ^
$3,899.00
CAN MSRP ^
$5,099.00
Engine Brand
Honda® GXV390
Engine Power Rating (hp)*
10.2
Displacement (cc)
389
PTO
Manual, Cable
Cylinders
1
Starter
Manual
Fuel Tank Capacity (gal)
0.55
Cutting Width (in)
32
Cutting Height (in)
1.5 - 5
Spindles
Aluminum Greaseable
Deck Construction
14 and 12-gauge
Transmission
Peerless axle with differential chain driven by Hydro-Gear® RT-310 pump and motor
Drive Axles (in)
0.75
Caster Tires (in)
10.5 x 3 Lockable Wheel
Drive Tires (in)
13 x 5-6
Ground Speed-Fwd (mph)
0 - 4
Ground Speed-Rev (mph)
0 -2
Overall Length (in)
73.5
Overall Width (in) Deflector Down/Deflector Up
44 / 32.5
Dry Weight (lbs)
285
Instrumentation
Speed Indicator
Safety Group/Controls
Blade Control Bail OPC
Warranty (Balance of Machine) †
2-year limited warranty commercial use, front-to-rear, parts & labor. Coverage on other components vary, please see operator’s manual for complete details. ¹
Warranty Commercial Product Info
3-year Limited engine warranty¹
Operator's Manuals
Operator's Manual - Spanish
Operator's Manual - English
Illustrated Parts List - English
Operator's Manual - English
Illustrated Parts List - English
¹ See operator’s manual or dealer for complete warranty details/ Refer to engine operator’s manual for engine warranty.
^ Suggested prices will vary by market. Set-up, delivery, documentation and destination fees not included. See dealer for details. Features vary by model. We reserve the right to change specifications, features and pricing without notice.
